Traverse Ten64

by Traverse Technologies

An eight-core ARM64 networking platform with mainline Linux support

View all updates Jul 05, 2020

New Board Revision and Call for Beta Testers

by Mathew M

Hello everyone,

Apologies for the very long wait between updates – at Traverse we have been very busy not only on the Ten64 but a couple of other ongoing projects – and we were unable to launch Ten64 last year as planned.

The Ten64 boards have been working well but we did identify a couple of issues that we could improve before the boards went into mass production – especially with regards to thermals and integration with both purpose-built and standard ITX enclosures.

Improved Rev B Boards

Improvements include:

  1. Some tuning of the PCB layout to reduce thermal hot spots on the board
  2. Added I/O panel buttons with LEDs to eliminate the need for a button and LED breakout board on a 'desktop' appliance case
  3. Tweaked the layout around the M.2 key B so a 5G (50 mm) card can sit entirely on the board
  4. Added a four-pin PWM fan header
  5. A much better looking soldermask!

Network Appliance

We will be offering two options in the campaign initially:

  • "Network Appliance" desktop cases
    • Runs off a 12 VDC power brick which will be included
  • Board only - for using in your own Mini-ITX cases
    • Including accessories such as ATX power cable adapter and I/O shield

The network appliance comes with 11 antenna mounts to support sub-6 5G and dual-band Wi-Fi applications. To keep things cool (and quiet!) a Noctua NF-A4x20 PWM fan is included.

Note that wireless cards/modems are not included with the appliance - as it is difficult to meet certification requirements on an "open" product - we do maintain a compatibility list of wireless cards that work.

Call for Beta Testers

We now have some boards available for beta testing and evaluation by the community. If you are interested, please fill out the contact form with answers to the following questions:

  • Why you are interested? For example, porting software, exploring interesting use cases etc.
  • Do you want just a bare board for your own ITX case, or do you want a desktop appliance?
  • Do you want 8, 16, or 32 GB of RAM?
  • Do you have any special requirements, like SATA controllers or SFPs? We are unable to supply Wi-Fi cards or cellular modems, but can supply the correct length antenna leads to use your own.
  • What is your approximate location (state/province and country)?

We’ll try to reply to all submissions within two weeks of receipt.

Update 2020-07-23: Beta tester applications are now closed! We received about ten times the number of applications as available boards, so it will take us a bit more time than planned to sort through them. Everyone who submitted an application will receive a response by the end of next week.

We have also started acquiring parts for a mass production run so we can turn over quickly after the campaign is completed – more information on that shortly. Issues around COVID-19 have slowed us down slightly but we are working through them.

In the meantime, check out the user manual and source repositories.

About the Author

Mathew M

mcbridematt  ·   Melbourne, Australia


$38,910 raised

of $60,000 goal

65% Funded

Pledge Now

$499

Ten64 Bare Board

This discounted, fully assembled, and tested mainboard comes with an ATX power adapter, heatsink fan, I/O faceplate, USB-C console cable, and optional RAM with ECC. Enclosure not included.


$579

Ten64 Complete Kit

This version of Ten64 is deeply discounted for this Crowd Supply campaign. A fully assembled and tested mainboard comes installed in a custom metal enclosure with a fan and optional RAM with ECC. Also included are a 60 W power supply with regional power cord, a USB-C console cable, a recovery microSD card, a SIM eject tool, and a hex key, as you'd expect with any good piece of hardware.


$850

Ten64 Turnkey NAS Bundle Optimized for HDD Bulk Storage

Looking for an HDD NAS? Other than the bulk storage drives themselves, this bundle includes everything you need for an HDD-bulk-storage NAS: tested and assembled Ten64 mainboard (with your choice of RAM), ATX power adapter, heatsink fan, I/O faceplate, USB-C console cable, four-port M.2 Key B SATA controller, four flexible SATA cables, NVMe SSD boot drive (with your choice of capacity), and InWin MS04-01 NAS enclosure, which features four 3.5" drive bays, 265 W power supply, and 6 Gb/s SATA backplane. Assembly required. Everything but the InWin enclosure is available separately.


$850

Ten64 Turnkey NAS Bundle Optimized for SSD Bulk Storage

Looking for an SSD NAS? Other than the bulk storage drives themselves, this bundle includes everything you need for an SSD-bulk-storage NAS: tested and assembled Ten64 mainboard (with your choice of RAM), ATX power adapter, heatsink fan, I/O faceplate, USB-C console cable, five-port M.2 Key M SATA controller, five flexible SATA cables,128 GB NVMe SSD boot drive, and InWin MS04-01 NAS enclosure, which features four 3.5" drive bays, 265 W power supply, and 6 Gb/s SATA backplane. Assembly required. Everything but the InWin enclosure is available separately.


$56

NVMe SSD

This SanDisk solid-state drive (SSD) fits inside the standard Ten64 enclosure and interfaces to the mainboard via NVMe. The 128 GB drive (P/N SDAPMUW-128G-1022) is compatible with both the M.2 Key M and M.2 Key B slots on Ten64's mainboard, whereas the 256 GB drive (P/N SDBPNPZ-256G) and 512 GB drive (P/N SDBPNPZ-512G) are only compatible with the M.2 Key M slot. These drives are only available when purchased with a Ten64. User installation required.


$70

NAS-grade SATA 2.5" SSD

These NAS-grade solid state drives (SSDs) are rated to last much longer than consumer models, so are perfect for NAS bulk storage. Choose from 256 GB (AP256GPPSS25-R), 512 GB (AP512GPPSS25-R), and 1 TB (AP1TPPSS25-R) capacities. These drives are only available when purchased with a Ten64. User installation required.


$55

Five-port M.2 Key M SATA Controller

We recommend this SATA controller for Ten64 NAS configurations using Apacer NAS-grade SSDs for bulk storage and a smaller 22 mm x 42 mm NVMe SSD for boot storage. This controller fits in the Ten64's M.2 Key M slot and uses two lanes of PCIe 3.0.


$55

Four-port M.2 Key B SATA Controller

We recommend this SATA controller for Ten64 NAS configurations using CMR HDDs for bulk storage and a standard 22 mm x 80 mm NVMe SSD for boot storage. This controller fits in the Ten64's M.2 Key B slot and uses one lane of PCIe 2.0.


$4

Flexible SATA Cable

One flexible cable (3M part number 5602-44-0142A-300) for connecting a SATA drive to a SATA controller board. You will need one cable per drive. Free shipping only available when shipped with another Ten64 product.
