XTRX Field Report Contest

XTRX: The sky's the limit

At Fairwaves, we love talking to our customers and a wider SDR community and take every opportunity to do so. From the practical business perspective, these discussions help us create products which scratch more than one itch and evolve them to satisfy many needs. At the same time, these talks are always fascinating as we learn about applications of the SDR technology which we couldn’t even imagine ourselves.

Now we want to share this fascination with more people and announce a call for Field Reports. Please send us a brief description of something cool you’re doing with XTRX - whether it’s a research project, hobby, or a commercial product, whether it’s open-source or proprietary, whether it’s on the ground, underwater or in the skies. We will publish the most exciting submissions in project updates, our newsletters, and other places. Author of each published field report will receive a $100 coupon to spend at Crowd Supply (should be spent within 30 days).

Email us your submission with “Field Report” as your subject line. Entries must be received by August 1st, 2019.

We created XTRX to be unlike other SDRs - to be embedded, ready for field deployments and mass products. SDR technology made possible many things which were hard to imagine before. With XTRX unique size and capabilities, XTRX users push the boundaries of possibility even further. Let’s tell the world!


$367,022 raised

of $90,000 goal

407% Funded! Order Below

Product Choices

$599

XTRX Pro

Get an XTRX Pro board. Does not include any cables, antennas, or adapter boards.


$799

XTRX Pro Deluxe Bundle

Get an XTRX Pro board as well as an Antennas + Cables set, a PCIe x2 + Front End Adapter, and a USB 3 Adapter with Aluminum Enclosure (see below for details). Also comes with four extra U.FL-to-U.FL cables and four extra U.FL-to-SMA-male cables.


$59

Antennas + Cables

A full complement of cables and antennas for your XTRX, including four RF antennas (95 mm, 2 dBi, SMA male, GSM/3G/LTE 880 - 960 MHz, 1710 - 1990 MHz), one GPS antenna, and five cables.


$99

PCIe x2 + Front End Adapter

This PCIe card securely holds an XTRX board (not included) so it can be used in a standard PCIe x4 slot. It includes an RF front end with a LNA and PA for up to 100 mW output on each channel. A TDD switch is incorporated for applications like TDD LTE. You can bypass the front end by attaching cables directly to XTRX. This adapter achieves the full 10 Gbit/s raw bus bandwidth and can be plugged into x4/x8/x16 PCIe slots. A six-pin JTAG connector makes it easy to program and debug the FPGA. A micro SIM card slot is also present.


$5,999

XTRX Pro PCIe Octopack

This single PCIe card comes loaded with eight (8!) removable XTRX Pro boards, metal installation brackets, enough cables for all GPS and MIMO Tx/Rx ports, and a special board for synchronizing all eight XTRX Pro boards.
