Jul 29, 2017

Next Batch of Boards and Aluminium Cases

Components arriving at our offices in Taipei for the next batch of 1,000 LimeSDR boards

While we have delivered most of the LimeSDR boards to our backers, there is presently a shortfall of few hundred boards. Of particular significance, we are very late with the delivery of the boards with the aluminium casing. We are working hard to address these issues, by manufacturing the boards now in batches of 1,000 units and we have already begun working with higher volume suppliers for the delivery of aluminium casing.

Most of the components for the LimeSDR board have been delivered and the hold-up is due to a few components that are expected to arrive by the 21st of August. They will go into SMT assembly immediately and the boards should be fully tested by the middle of September. It will take a further week for packaging and shipping to Crowd Supply, so backers should see their units arriving around the end of September.

We have asked for another 100 units of the aluminium casing to be delivered to us by the middle of August. Assembly and shipping to Crowd Supply will take a further week. We expect the next 100 units to be shipped to backers by the end of August. The rest of the units will be shipped in October.

Given the increasing popularity of the LimeSDR and with so many backers spread across the world, we are planning to keep larger volumes of stock so that your future orders should only take a few days to be delivered. We shall provide you with updates on this as soon as we have finalised our higher volume manufacturing plans with our ODM partners.

As always, you can check the status of your order by logging into your Crowd Supply account.

Many thanks for all your support!

Ernie and the LimeSDR team

$1,343,415 raised

of $500,000 goal

Funded! Order Now

Jun 21 2016

funded on

268%

funded

5,343

pledges

Product Choices

$299

LimeSDR

The LimeSDR is based on Lime Microsystem’s latest generation of field programmable RF transceiver technology, combined with FPGA and microcontroller chipsets. These connect to a computer via USB3. LimeSDR then delivers the wireless data and the CPU provides the computing power required to process the incoming signals, and to generate the data to be transmitted by the LimeSDR to all other devices.


$99

Acrylic Case

A layered acrylic case to protect your LimeSDR. Can be used with either USB Type A or micro USB Type B. Antenna not included - separate purchase available.


$599

LimeSDR with Aluminum Kit

Start developing apps based on Lime Microsystem’s latest generation of field programmable RF transceiver technology. This board comes with fancy aluminum casing. The board will be delivered with turnkey support for a diverse range of SDR ecosystem software, a powerful API and rapid prototyping environment. All the boards in this category will come with a fancy Aluminum casing coated with high quality material, cables, and antennas for a quick set up.


$799

Ultimate LimeSDR With PCIe Interface

Start developing apps based on Lime Microsystem’s latest generation of field programmable RF transceiver technology. The board will be delivered with turnkey support for a diverse range of SDR ecosystem software, a powerful API and rapid prototyping environment. All the boards in this category will come with a PCIe interface, cables and Antennas for a quick set up.


$85

Four Antenna + Cable Pairs

Omni-directional antenna set, covering frequency ranges 800-960 MHz, 1710-2170 MHz, and 2400-2700 MHz. Includes U.FL to SMA cables.


$169

GPIO Board

This stackable expansion board for the LimeSDR provides individually settable, bi-directional level-shifted I/O for FPGA GPIO 0-7. Each I/O has a high-voltage and power Darlington drive stage suitable for inductive loads, such as coaxial relays. LimeSDR not included.


$79

Hacker Case

This custom acrylic case accommodates both a LimeSDR and a GPIO Board, and includes SMA connectors for all RF ports, two SMA connectors for clock I/O, and a 40 mm cooling fan. LimeSDR and GPIO Board not included.
