View all updates Oct 06, 2020

All Kits Shipped to Warehouse

by ANAVI Technology

We have shipped all ANAVI Fume Extractor kits to the warehouse. They are expected to arrive next week, and then the Crowd Supply team will start shipping them to you soon. If you need to update your shipping address, please visit your account page.

ANAVI Fume Extractor is made in my hometown Plovdiv, Bulgaria. Here we use the Cyrillic script as a writing system. Have ever wondered how to write "fragile" in Bulgarian? It is "чупливо", and if you look closer you will see on the red labels on each of the 4 big boxes with ANAVI Fume Extractor kits :)

Each ANAVI Fume Extractor kit has been packaged in a cardboard box. Components are bubble wrapped for extra security during the transportation. Remember to peel off the protective film from both sides of the acrylic enclosures and be very careful with the mini OLED display because it is fragile. Please follow the exact steps in the assembly guidelines.

It is time for Hacktoberfest and your contributions to our git repositories in GitHub are more than welcome. Everything is open source. Furthermore, we use only free and open source tools. Thank you for supporting this project. We rely on the community to make ANAVI Fume Extractor even better!

Thanks, Leon

About the Author

ANAVI Technology

AnaviTechnology  ·  AnaviTechnology  ·   Plovdiv, Bulgaria


$6,600 raised

of $1 goal

Funded! Order Below

Product Choices

$49

Starter Kit

The perfect kit for getting started. Includes ANAVI Fume Extractor PCB (1), 5 V DC 80x80 mm fan (1), acrylic enclosure (1), filters (2), 0.96" OLED display (1), and USB-to-serial debug cable (1).


$59

Advanced Kit

The kit for makers. Includes ANAVI Fume Extractor PCB (1), 5 V DC 80x80 mm fan (1), acrylic enclosure (1), filters (2), 0.96" OLED display (1), USB-to-serial debug cable (1), HTU21D temperature, and humidity sensor (1) and MQ-135 gas sensor (1).


$69

Developer Kit

Everything a developer needs! Includes ANAVI Fume Extractor PCB (1), 5 V DC 80x80 mm fan (1), acrylic enclosure (1), filters (2), 0.96" OLED display (1), USB-to-serial debug cable (1) and all sensor modules: HTU21D temperature and humidity sensor (1), MQ-135 gas sensor (1), BH1750 light sensor (1), and BMP180 temperature and barometric pressure sensor (1).


$219

Family Kit

The ultimate solution that features a developer kit and three advanced kits.
