View all updates Feb 25, 2020

Manufacturing Progress!

by Gino Magarotto

Progress!

Our PCB house resumed its fabrication work this week. The solder paste stencils have not yet been manufactured, but we expect them to enter production shortly. Our other vendors are also getting back to work, and parts should be shipping soon. We are looking forward to picking up the pace in March and getting started on the work of assembling the machines themselves.

As for the items we ordered from North American manufacturers, we’ve been told that the Betztechnik nozzle holders are ready to ship!
