DCP405 Modules Are In

by Denis Kotlar (a.k.a. prasimix)

After a long break, the DCP405 modules have finally begun to arrive. The first (smaller) batch showed up this morning, and two larger batches will follow. Once we’ve tested these modules, we will start packing everything up and shipping it to Crowd Supply’s fulfillment partner, Mouser Electronics.

Revising the Estimated Ship Date

We’re getting very close, but we do not expect BB3s to ship out to backers within the next ten days, so we’ve pushed our estimate back to early August. We’ll keep you posted if that changes.
