Feb 23, 2017

PCIe, Aluminium Cases, and HF Mod

We are pleased to report the LimeSDR PCIe boards are now with us, are being put through final testing, and will be shipped out to Crowd Supply tomorrow. These will be packaged in a protective case, along with the accessories, before being sent out to backers.

Speaking of cases, we’ve had confirmation that the aluminium cases for the LimeSDR USB Type-A boards are due to arrive at our offices on March 20, 2017. Following which they will be sent on to Crowd Supply and orders with these put together and shipped out to backers. We can only apologise for the delay, but we were not prepared to compromise on the quality and are sure you will agree it was worth the wait.

Finally, now that the survey results are in, we can schedule the production of boards for those backers who requested modification for HF use. Having considered the various options available, it has been decided that the inductor will be removed from the RX1_W input, leaving the RX1_L input optimised for key applications which use higher frequencies.

Andrew and the LimeSDR Team
