ANAVI Fume Extractor

by Anavi Technology

The open source smart solder smoke absorber

View all updates Jul 23, 2020

Manufacturing Update

by ANAVI Technology

A quick manufacturing update regarding ANAVI Fume Extractor:

  • We stocked 09325-M/45 PPI foam media filters. Initially the plan was to use another model from a European supplier but they ran out of stock. Crowd Supply came to the rescue and help us quickly buy 09325-M/45 from Mouser. DHL delivered them today. They fit perfectly on the 80mm fan. The color is slightly different from the filter which we used for the video and photos on the campaign page. Each kit with ANAVI Fume Extractor will include 2 filters.
  • The first small batch of printed circuit boards is expected from the local factory in Plovdiv, Bulgaria by the end of next week.

Thank you again for supporting the open project ANAVI Fume Extractor. So far there no delays and manufacturing is happening at a good pace. We will keep you updated with any progress!

Best regards, Leon

About the Author

ANAVI Technology

AnaviTechnology  ·  AnaviTechnology  ·   Plovdiv, Bulgaria


$6,531 raised

of $1 goal

Funded! Order Below

Product Choices

$49

Starter Kit

The perfect kit for getting started. Includes ANAVI Fume Extractor PCB (1), 5 V DC 80x80 mm fan (1), acrylic enclosure (1), filters (2), 0.96" OLED display (1), and USB-to-serial debug cable (1).


$59

Advanced Kit

The kit for makers. Includes ANAVI Fume Extractor PCB (1), 5 V DC 80x80 mm fan (1), acrylic enclosure (1), filters (2), 0.96" OLED display (1), USB-to-serial debug cable (1), HTU21D temperature, and humidity sensor (1) and MQ-135 gas sensor (1).


$69

Developer Kit

Everything a developer needs! Includes ANAVI Fume Extractor PCB (1), 5 V DC 80x80 mm fan (1), acrylic enclosure (1), filters (2), 0.96" OLED display (1), USB-to-serial debug cable (1) and all sensor modules: HTU21D temperature and humidity sensor (1), MQ-135 gas sensor (1), BH1750 light sensor (1), and BMP180 temperature and barometric pressure sensor (1).


$219

Family Kit

The ultimate solution that features a developer kit and three advanced kits.
